Hydrological Open Air Laboratory HOAL Petzenkirchen (Satellite)

Operator: Institute for Land and Water Management Research (IKT Petzenkirchen), Vienna University of Technology
DEIMS-SDR Database: HOAL Petzenkirchen
Contact: Gerhard Rab

Site description

The Petzenkirchen HOAL (Hydrological Open Air Laboratory) catchment is situated in the western part of Lower Austria (48°9' N, 15°9' E). The catchment area at the outlet (termed MW) is 66 ha. The elevation of the catchment ranges from 268 to 323ma.s.l. with a mean slope of 8 %. At present, 87 % of the catchment area is arable land, 5 % is used as pasture, 6 % is forested and 2 % is paved. The crops are mainly winter wheat and maize. The climate can be characterised as humid with a mean annual temperature of 9.5 °C and a mean annual precipitation of 823 mm/yr from 1990 to 2014. Precipitation tends to be higher in summer than in winter. Crop evapotranspiration (ETc) estimated by the FAO (1998) method using local climate data and crop growth information for this period was 471 mm/yr. Annual evapotranspiration estimated by the water balance ranged from 435 to 841 mm with a mean of 628 mm/yr (1990 – 2014) (assuming deep percolation is negligible). The natural surface water outlet of the catchment is known as the Seitengraben stream. Mean annual flow from the catchment in this stream is 4.1 L/s (or 195 mm/yr) (1990 – 2014). Mean flows tend to peak in the spring. The largest flood events on record occurred in 1949 and 2002 with estimated peak discharges of 2,800 and 2,000 L/s, respectively. The highest discharge in recent times occurred in summer 2013 with 660 L/s. The subsurface consists of Tertiary sediments of the Molasse zone and fractured siltstone. The dominant soil types are Cambisols and Planosols with medium to poor infiltration capacities. Gleysols occur close to the stream. (Blöschl et al., 2016)

Publications
